5KiloWatt Roof Solar Panel array, Hybrid Inverter installation project

Client Name : Suryakumar

Capacity:7.5KW

Address: Saptagiri medical colony bangalore, india

you can spot the PV panels beside selfie resturant

7.5KiloWatt Roof Top Solar Panal array+ Hybrid Inverter installation project

This is my very first large scale project as an Enginner out in the fields so i am sharing this for everyone

solar panal CLASS A 250 watt

total 30 panals in two different arrays of 15 each.

 A rooftop photovoltaic power station, or rooftop PV system, is a photovoltaic system that has its electricity-generating solar panels mounted on the rooftop of a residential or commercial building or structure.^[1] The various components of such a system include photovoltaic modules, mounting systems, cables, solar inverters and other electrical accessories.^[2]

Rooftop mounted systems are small compared to ground-mounted photovoltaic power stations with capacities in themegawatt range. Rooftop PV systems on residential buildings typically feature a capacity of about 5 to 20 kilowatts (kW), while those mounted on commercial buildings often reach 100 kilowatts or more.

Installation

Time of the yearThe urban environment provides a large amount of empty rooftop spaces and can inherently avoid the potential land use and environmental concerns. Estimating rooftop solar insolation is a multi-faceted process, as insolation values in rooftops are impacted by the following:

• Latitude
• Weather conditions
• Roof slope
• Roof aspect
• Shading from adjacent buildings and vegetation

There are various methods for calculating potential solar PV roof systems including the use of Lidar^[4] and orthophotos.^[5] Sophisticated models can even determine shading losses over large areas for PV deployment at the municipal level.

click on the video to have a look at the project in action mode

Hybrid systems

Rooftop PV hybrid system.

A rooftop photovoltaic power station (either on-grid or off-grid) can be used in conjunction with other power sources like diesel generators,wind turbine etc. This system is capable of providing a continuous source of power.

Advantages

Installers have the right to feed solar electricity into the public grid and hence receive a reasonable premium tariff per generated kWh reflecting the benefits of solar electricity to compensate for the current extra costs of PV electricity.
